TORCH T1100 Manual Stencil Printert-Screen Printer made in China

FOB Reference Price:Get Latest Price
$2,900.00 - $3,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Color & Page:
Single Color
Certification:
ISO9001
Gross Power:
50W
Usage:
solder printer
Plate Type:
Screen Printer
Condition:
New
Place of Origin:
Beijing, China
Brand Name:
TORCH
Model Number:
T1100
Automatic Grade:
manual
Voltage:
380V
Dimensions(L*W*H):
1000*1000*1250mm
Weight:
120kg
max print area:
220 *180mm, 220*240mm (optional)
Suggest template size:
350*400mm, thickness is 20mm
PCB thickness:
0.2-2.0mm
Table size:
300*300mm
Power supply:
AC220V 50Hz
repeat accuracy:
±0.05mm
Ideal printing accuracy:
0.4mm QFP; >0.4mm (ball diameter) BGA
Dimension:
740*554*400mm
After-sales Service Provided:
Overseas third-party support available
Warranty:
1 year
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden package or as your requirement
Port
tianjin
Lead Time :
15-20 days after receiveing the all payment
High precision semi-automatic screen printing machine T1100

T1100 provide security, operator just need to press double-switch operating button, the machine will complete the whole printing process automatically. When the printing process is completed, operating stuff take out of PCB board and put it in boxes or into pick and place machine directly, and then put another piece of PCB board into the operating bench, another round begins.

T1100 uses SMC, Panasonic, Omron and other imported components, using PLC to control internal procedures.

T1100 equips imported linear guiderail, it features easy to operate, high precision, easy adjustment and a wide range of usage.

T1100 employs advanced PLC program control, with high precision control and low fault rate;

T1100 template's lifting and scraper's UPS and downs are driven by cylinder. Air-inlet and air-outlet is equipped with speed control valve, the cylinder speed can be easily adjusted.

T1100 scraper movement is driven by the motor, motor speed can be adjusted by motor speed controller;

T1100 scraper support moves by high-precision linear guide rail to ensure smooth, precision and stable movement.

T1100 scraper is stainless steel material and floating structure to ensure the stress even in the printing process.

TypeT1100
Max printing size220 × 180mm, 220×240mm (optional)
Suggest template size350×400mm, thickness is 20mm
PCB thickness0.2-2.0mm
Table size300×300mm
Working press0.4-0.7 Mpa
Holes space of knock pin20mm    screw:M5
Power supplyAC220V 50Hz
Max power60W
Adjusting rangeX axis +10mm ; Y axis ±10mm
Repeat accuracy±0.05mm
Ideal printing accuracy  0.4mm QFP;  >0.4mm (ball diameter) BGA
Dimension740×554×400mm
