TORCH Semiautomatic Stencil Printer/Screen Printer for PCB printing T1100

FOB Reference Price:Get Latest Price
$1.00 - $2.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
T1100
Gross Power:
60W
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Color & Page:
Multicolor
Certification:
CE certification
Usage:
solder printer
After-sales Service Provided:
Online support
Plate Type:
Screen Printer
Condition:
New
Place of Origin:
Anhui, China
Brand Name:
TORCH
Automatic Grade:
manual
Voltage:
AC220V 50Hz
Dimensions(L*W*H):
740*554*400mm
Weight:
30kg
print area:
220 *180mm, 220*240mm (optional)
Suggest template size:
350*400mm, thickness is 20mm
PCB thickness:
0.2-2.0mm
Table size:
300*300mm
Power supply:
AC220V 50Hz
repeat accuracy:
±0.05mm
Ideal printing accuracy:
0.4mm QFP; >0.4mm (ball diameter) BGA
Dimension:
740*554*400mm
Working press:
0.4-0.7 Mpa
Holes space of knock pin:
20mm screw:M5
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden package or as your requirement
Port
tianjin
High precision semi-automatic screen printing machine T1100

T1100 provide security, operator just need to press double-switch operating button, the machine will complete the whole printing process automatically. When the printing process is completed, operating stuff take out of PCB board and put it in boxes or into pick and place machine directly, and then put another piece of PCB board into the operating bench, another round begins.

T1100 uses SMC, Panasonic, Omron and other imported components, using PLC to control internal procedures.

T1100 equips imported linear guiderail, it features easy to operate, high precision, easy adjustment and a wide range of usage.

T1100 employs advanced PLC program control, with high precision control and low fault rate;

T1100 template's lifting and scraper's UPS and downs are driven by cylinder. Air-inlet and air-outlet is equipped with speed control valve, the cylinder speed can be easily adjusted.

T1100 scraper movement is driven by the motor, motor speed can be adjusted by motor speed controller;

T1100 scraper support moves by high-precision linear guide rail to ensure smooth, precision and stable movement.

T1100 scraper is stainless steel material and floating structure to ensure the stress even in the printing process.
TypeT1100
Max printing size220 × 180mm, 220×240mm (optional)
Suggest template size350×400mm, thickness is 20mm
PCB thickness0.2-2.0mm
Table size300×300mm
Working press0.4-0.7 Mpa
Holes space of knock pin20mm    screw:M5
Power supplyAC220V 50Hz
Max power60W
Adjusting rangeX axis +10mm ; Y axis ±10mm
Repeat accuracy±0.05mm
Ideal printing accuracy  0.4mm QFP;  >0.4mm (ball diameter) BGA
Dimension740×554×400mm
